Flight type dishwashing machine for trays MEIKO BTA 160 AND 240

Servicing and technical data

tray dishwasher BTA 160 240
Experience the machine

ADVANTAGES

  • Quick and efficient tray washing with low operating costs

  • Automated modules mean it is unnecessary to manually handle the trays

  • Flawless cleaning and drying results with technology specially adapted for trays

  • A stacking device at the discharge section ensures uninterrupted operation while the tray stacking device is quickly and securely swapped

Up to
24
TRAYS PER MINUTE

Trays are no longer manually loaded into a dishwashing machine. Instead, the conveyor automatically moves, washes and dries them – even stacking them after cleaning. That means shorter washing and working times, lower energy consumption and thus lower costs.

MODELS

for 16 or 24 trays per minute

This automatic flight type dishwashing machine for trays gives you everything you would expect of MEIKO at excellent value for money. And the compact design will fit neatly into nearly any dishwashing area.

160

Drying/Air Circulation200 m³/h
Pump motor1,1 kW
Fan motor4 kW
Final rinse150 l/h
more technical data
240

Drying/Air Circulation2 x 200 m³/h
Pump motor1,1 kW
Fan motor2 x 4 kW
Final rinse225 l/h
more technical data
MEIKO BTA 160

This model of tray washer can automatically wash up to 16 trays per minute.

A powerful washing system located both above and below the tray delivers flawless cleaning results. This is followed by an intensive hot fresh water final rinse of each tray. The final rinse and drying zones are separated to ensure that the trays are transported on dry round belts inside the drying zone.

Measurements
BTA 160 dimensions
Drying/Air Circulation200 m³/h
Pump motor1,1 kW
Fan motor4 kW
Final rinse150 l/h
Washing performance16 Trays/h
Built-in boiler 40°C Supply temperature13,9 kW
Built-in boiler 10°C Supply temperature17,6 kW
Total connection 10°C inlet temperature without heat recovery39 kW
Total connection 10°C inlet temperature with heat recovery33 kW
Total connection 40°C inlet temperature29 kW
Tank filling60 l
MEIKO BTA 240

This model can automatically wash and dry up to 24 trays per minute.

The compact construction, high capacity and exceptional price-performance ratio make this model an ideal choice. Trays no longer need to be picked-up and placed on the dishwashing machine belt manually. This keeps costs lower with shorter wash cycle times, reduced working hours and less energy consumption.

Measurements
Tray washer dimensions
Drying/Air Circulation2 x 200 m³/h
Pump motor1,1 kW
Fan motor2 x 4 kW
Final rinse225 l/h
Washing performance24 Trays/h
Built-in boiler 40°C Supply temperature13,9 kW
Built-in boiler 10°C Supply temperature17,6 kW
Total connection 10°C inlet temperature without heat recovery47 kW
Total connection 10°C inlet temperature with heat recovery40 kW
Total connection 40°C inlet temperature36 kW
Tank filling60 l

Product lines and versions may vary by country due to statutory requirements or other reasons. Please ask your local contract partner. They will be happy to find a machine that meets your specific requirements.
Version: 06/2018. We reserve the right to make changes as part of product improvements.
